Raymarine Cyclone 55 Watts 6ft Open Array Radar with 15m Cables

Raymarine Cyclone 55 Watts 6ft Open Array Radar with 15m Cables

Raymarine Cyclone 55 Watts 6ft Open Array Radar with 15m Cables are a high-performance, solid-state marine radar that uses CHIRP pulse compression and beam sharpening technology for superior target separation and long-range resolution, with a maximum range of up to 72 nautical miles.

Raymarine Cyclone 55 Watts 6ft Open Array Radar with 15m Cables Key Features

• Solid-State Transmitter: Features a 55-watt solid-state transmitter, which offers performance equivalent to a 6 kW magnetron radar.
• Advanced Imaging: Delivers high-speed 60 RPM rotational speed for 360 degrees of awareness and accurate, real-time target tracks, even at high boat speeds.
• Doppler Target Tracking: Simplifies navigation by automatically color-coding moving targets (red for inbound, green for outbound) to quickly identify potential collision risks.
• RangeFusion™ Technology: Combines short and long pulses into a single, high-clarity radar image, providing excellent short-range and long-range target detection simultaneously.
• Bird Mode: An innovative feature that automatically optimizes gain and tune settings to intelligently image and locate distant sea birds, which helps anglers find fish.
• Durability: Engineered with an aircraft-wing-inspired design, it boasts a best-in-class 100-knot wind rating and meets the commercial-grade IEC 62388 standard for shipborne radar.
• ARPA Target Tracking: Capable of professional-grade automatic tracking of up to 50 ARPA targets simultaneously, providing crucial data like bearing, speed, and closest point of approach (CPA).
• Design & Installation: Features a low profile (13.1 inches tall) and an innovative pedestal design that conceals cable connections for a cleaner installation.
• Connectivity: Equipped with a RayNet connector for seamless integration with compatible Raymarine Axiom multifunction displays.
• Included Components: The package includes the 55 watt pedestal, a 6-foot antenna array, 15m cable kit, and a VCM100 voltage convertor

Raymarine Cyclone 55 Watts 6ft Open Array Radar with 15m Cables FAQs

• What are the key features of the Raymarine Cyclone radar ?
  • Technology: Employs CHIRP pulse compression and beam sharpening.
  • Performance: Offers 60 RPM imaging for real-time awareness and tracking.
  • Durability: Features a design with a 100-knot wind rating, meeting IEC 62388 commercial-grade standards.
  • Detection Modes: Includes Cyclone Bird Mode and RangeFusion™ technology.
  • Safety: Incorporates Doppler target tracking to highlight dangerous and safe targets.
• What is the maximum range of the radar? The theoretical maximum range is 72 nautical miles (NM). Actual detection range depends on factors like scanner installation height and target height.
• Is this radar compatible with all Raymarine displays? It's designed for seamless integration with Raymarine Axiom, Axiom+, Axiom Pro, and Axiom XL multifunction displays. It is not compatible with older systems requiring analogue scanners.
• What is included in the package? The package typically contains the 6-foot antenna array, pedestal unit, 15-meter cable kit, and the VCM100 voltage converter module.
• What is the optimal mounting height for the scanner? Mount the scanner as high as possible for better long-range performance, as radar is line-of-sight. It should also be above head height for safety.
• Do I need a special license or certificate to use this radar? Licensing requirements may vary by national administration. Check with local authorities or your Raymarine dealer.
• Can I use my existing radar cables when upgrading? Typically, upgrading requires new interconnect cables. Adapter cables may be available for some older models, but consulting with a professional or Raymarine support is recommended.
