Garmin Striker Vivid 7cv with GT20-TM Transducer

CLEAR, COLOURFUL SONAR
Choose from 7 new vivid colour options to see fish and structure in maximum contrast and clarity on your 7-inch Fishfinder.

BUILT-IN SONAR
Use the included GT20 transducer to get Garmin CHIRP traditional sonar and CHIRP ClearVü scanning sonar.

WAYPOINT MARKING
To catch more fish, you need to know where the fish are biting. Use waypoint marking for hot spots so you can easily find your way back.

HIGH-SENSITIVITY GPS
Plan and create routes and view your boat’s speed on your Fishfinder using high-sensitivity GPS.

QUICKDRAW CONTOURS
Nobody knows the waters you fish better than you. With the STRIKER Vivid 7cv Fishfinder, you can store up to 2 million acres of maps with 1-foot contours.

INCLUDED HARDWARE
The STRIKER Vivid 7cv includes a tilt/swivel mount plus transom and trolling motor mounting hardware and cable.

WI-FI CONNECTIVITY
Connect to the ActiveCaptain® app1 to transfer waypoints, receive smart notifications (including software update notifications) and access the Garmin Quickdraw™ Community.

Specifications

General:
Dimension    9.3” x 5.5” x 2.3” (23.5 x 14.0 x 5.8 cm)
Weight    1.7 lbs (0.8 kg)
Water rating    IPX7
Display Type    WVGA colour
Display Size    3.4" x 6.1" (8.6 x 15.4 cm); 7.0" diag (17.8 cm)
Display Resolution    800 x 480 pixels
Mounting Options    flush, tilt/swivel
Input    Keyed

Maps & memory:
Waypoints/favourites/locations     5000
Track points    50,000
Tracks    50
Navigation Routes    100

Sensors:
GPS    Yes
Has built-in receiver    Yes
Supports WAAS    Yes
Optional map support
Garmin Quickdraw Contours    Yes

Electrical features:
Power Input    12 to 20 Vdc
Typical current draw    0.55 A
Max current draw    1.5 A
Power Consumption    6.6

Sonar features & specifications:
Displays sonar    Yes
Traditional sonar (dual frequency/beam)    Built-in
ClearVü    Yes
Frequency    Traditional: 50/77/200 kHz CHIRP (mid and high) ClearVü: 260/455/800 kHz
Transmit power    500 W (RMS)
Bottom Lock (shows return from the bottom up)    Yes
Water Temperature Log    Yes

Connections:
4-pin transducer ports    1
Garmin Wi-Fi network (local connection)    Yes

Fishfinder features:
Split-screen zoom    Yes
Fish Symbol ID (helps identify fish targets)    Yes
AutoGain Technology (minimises clutter, maximises targets)    Yes
Adjustable depth line (measures depth of underwater objects)    Yes
A-scope (real time display of fish passing through transducer beam)    Yes
Water temperature sensor included    Yes
Depth range shading    Yes

in the box
STRIKER Vivid 7cv
GT20-TM transducer
Power/data cable
Tilt/swivel mount
Hardware
Garmin bumper sticker
Documentation
