Extreme EXT 750 Swing Roller Trailer

Extreme EXT 750 Swing Roller Trailer

Extreme EXT 750 Swing Roller Trailer are one of the most versatile trailers in the Extreme range, the EXT 750 is designed and manufactured right here in the UK. Whether you’re launching a RIB, a hard boat, or a dinghy, this trailer’s "swing" cradle technology makes launching and recovery remarkably effortless—even in shallow water or challenging tidal conditions.

The standout feature of this model is the adjustable swinging arm at the rear. Unlike fixed trailers, the swing cradle pivots to meet your boat's hull, providing a self-centring action that guides your craft perfectly onto the rollers every time. Combined with a heavy-duty, fully galvanised frame, this trailer is built to withstand the rigours of the British marine environment.

Extreme EXT 750 Swing Roller Trailer Key Features

• Superior Support: Equipped with 12 non-marking nylon wobble rollers and 2 heavy-duty keel rollers, ensuring your hull is cradled safely without unsightly scuffs.
• Fully Adjustable: Everything on this trailer is adjustable, meaning we can tailor the fit to almost any hull shape for a secure, "snug" tow.
• Built to Last: Features an AL-KO axle with waterproof sealed bearings, significantly extending the life of your hubs and reducing maintenance.
• Complete Package: Includes a heavy-duty height-adjustable winch post, a 1000lb manual winch, and a lightboard on extendable bars as standard.
• Easy Manoeuvring: Comes with 10" wheels and a 42mm jockey wheel with a cast clamp for easy movement when unhitched.

Technical Data:

• •  Weight750kg
  • Carrying Capacity580kg
  • Trailer Weight170kg
  • Overall Length5.25m
  • Overall Width1.85m
  • Max Boat Length
    • Hard boats up to 16',
    • RIBs up to 5.3m,
    • Dinghies up to 17'

Morgan Marine Expert Tip: If you aren't sure if this is the right fit for your craft, our team has over 50 years of experience to help guide you. We want to ensure your boat sits comfortably and safely on its "wheeled cradle."

Extreme EXT 750 Swing Roller Trailer FAQs

What type of boats is the EXT 750 Swing suitable for?
The EXT 750 Swing is a versatile, heavy-duty trailer. It is perfectly suited for:

• • Dinghies: Up to 17ft (with overhang).
  • Hard Boats (Fishing/Speed): Up to 16ft.
  • RIBs: Up to 5.3m.

If you are unsure if your specific hull will fit, please get in touch with our team at the Brightlingsea boatyard.

What is the difference between the "Swing" and the standard Roller trailer?

The "Swing" refers to the adjustable swinging arm at the rear of the trailer. This allows the rear rollers to pivot and find the hull of your boat as you approach, making it significantly easier to self-centre your boat during recovery. It is especially useful if you often launch alone or in windy conditions.

What is the maximum weight capacity?

The trailer has a Gross Vehicle Weight (GVW) of 750kg. The trailer itself weighs approximately 170kg, leaving you with a generous carrying capacity (payload) of 580kg. This must include your boat, engine, fuel, and any gear stored on board while towing.

Is this trailer braked or unbraked?

The EXT 750 is an unbraked trailer. Under UK law, you can tow an unbraked trailer up to 750kg, provided it does not exceed 50% of your towing vehicle's kerb weight.

Will it rust in salt water?

Extreme trailers are built for the marine environment. The frame is hot-dipped galvanised to protect against corrosion. Additionally, this model comes standard with waterproof sealed bearings, which are essential for longevity if you are launching into the sea. We always recommend a quick fresh-water rinse after every immersion to keep it in top condition.

Are the rollers "non-marking"?

Yes. The EXT 750 Swing is fitted with 12 high-quality, non-marking wobble rollers and 2 heavy-duty keel rollers. Unlike cheaper black rubber rollers, these will not leave unsightly scuffs or marks on your gelcoat or RIB tubes.

Is the trailer adjustable for different hull shapes?

Absolutely. Almost everything on this trailer is adjustable, including the winch post, the height of the rollers, and the position of the axle. This ensures we can achieve the perfect balance and support for your specific boat.

Does it come with a lighting board?

Yes, every Extreme trailer purchased from Morgan Marine comes with a lighting board on extendable galvanised bars as standard. You won’t need to worry about purchasing this separately to be road-legal.

What else is included in the price?

When you buy from our shop, you receive a complete ready-to-tow package:

• • Heavy-duty winch (1000lb - 1400lb depending on current spec).
  • 42mm telescopic jockey wheel with cast clamp.
  • Certificate of Conformity (Required for legal use in the UK and Europe).

Can I have it delivered, or do I need to collect?

We offer nationwide UK delivery directly from our Essex base. Alternatively, you can select 'Local Pickup' at checkout to collect from us here in Brightlingsea. If you choose to collect, our engineers can often help you adjust the trailer to fit your boat perfectly on the day.

What is the lead time for an Extreme trailer?

We aim to keep the EXT 750 Swing in stock due to high demand. If it is in stock, delivery usually takes 3-5 working days. If we are awaiting a shipment from the manufacturer, we will contact you immediately with an estimated timeframe.

Why should I buy from Morgan Marine?

We’ve been in the marine industry since 1972. When you buy from us, you aren’t just getting a box-shifter service; you’re getting the support of a full-service boatyard. We use these trailers ourselves in our Park & Ride service, so we know exactly how reliable and robust they are.

Still have questions?

Our technical team is available 7 days a week. Give us a call on 01206 302003 or email us at enquiries@morganmarine.com and we’ll be happy to help you get on the water!
